DMP Electronics XR500 SERIES Programming Guide

XR500 Series Canadian Programming Guide Digital Monitoring Products
17
DEVICE SETUP
If you do not enter any area numbers, all users with Door Access authority receives a
dooraccesswithoutregardtoschedules.IftheusercodeisprogrammedforAnti-Pass
YES, then the user is logged into all matching areas. This user is not allowed to access
these areas again until they have egressed the area. See Egress Areas.
When all areas accessed by a door are armed, the door is locked by the panel.
Note: For an All/Perimeter, Home/Sleep/Away, or Home/Sleep/Away with Guest
system, Access Areas should be left at factory default settings.
6.7 Egress Areas
Press the COMMAND key to program Egress Areas. To select an area, enter the area
number using the digit keys on the keypad. When an area is selected, an asterisk
appears next to the area number. Enter the number again to deselect the area.
Press COMMAND to display the next set of areas. Refer to the Multiple Displays
section at the beginning of this document.
Note: For an All/Perimeter, Home/Sleep/Away, or Home/Sleep/Away with Guest
system, Egress Areas should be left at factory default settings.
Note: If an area is programmed as an access area, it cannot be programmed as an
egress area and therefore does not display during Egress Areas programming.
UsethisoptiontodetectAnti-passbackviolations.Anti-passbackrequiresauserto
properlyexit(egress)anareatheyhavepreviouslyaccessed.Ifusersfailtoexit
through the proper card reader location they are not granted access on their next
attempt.Usersmusthavematchingaccessareanumbersassignedtotheirprole,
toreceiveadooraccessatthisdevice.IftheuserisprogrammedforAnti-Pass
YES, then the user is logged out of all matching areas. This allows the user to again
access the area. See Access Areas section.
If you do not enter any area numbers, all users with Door Access authority receives a
dooraccesswithoutregardtoschedules.IfyouarenotusingtheAnti-Passfeature
leave Egress Areas blank.
6.8
DISPLAY AREAS:
Display Areas
*1 *2 *3 *4
*5 *6 *7 *8
*9 *10 *11 *12
*13 *14 *15 *16
*17 *18 *19 *20
*21 *22 *23 *24
*25 *26 *27 *28
*29 *30 *31 *32
Press the COMMAND key to program Display Areas. To select an area between 1 and
32, enter the area number using the keypad digit keys. When an area is selected, an
asterisk appears next to the area number. Enter the number again to deselect the
area. Press COMMAND to display the next set of areas. Default is all area numbers.
Refer to the Multiple Displays section at the beginning of this document.
Display Areas allows the XR500 Series burglary activities to be segmented so that
onlyspecicarea(s)andtheirassociatedoperationappearataparticularkeypad.
Areanumber(s)selectedinthiseldaffectthewayusersinteractwiththesystem
from this particular device. For example: Program Device 1 to show only the zone
activities and armed status of Area 1.
Entertheareanumber(s)thatthiskeypadistodisplay.Thisallowsspecicareacontrol
fromspecickeypads,aswellasannunciationofzonesassignedtothosearea(s).When
DisplayAreasisleftdefaulted(allareasselected),MenuDisplayandStatusListitems
determine whether zone alarms and troubles display at this device, regardless of area
assignment. Also, all system areas may be armed and disarmed from this device.
Note: For an All/Perimeter or Home/Sleep/Away system, Display Areas should be
left at factory default settings.
ForHome/Sleep/AwaywithGuestarmingsystems,theDisplayAreasselection
determines which system the keypad arms and disarms. With areas 1, 2 or 3 being
therstareasselected,thekeypadisassignedtotheMainsystem.Witharea4,5or6
beingtherstareasselected,thekeypadisassignedtotheGuest1system.Witharea
7,8or9beingtherstareasselected,thekeypadisassignedtotheGuest2system.
Keypads can have additional areas assigned for Event Display.
User Action Allowed
Whenanarea(s)isselected,thefollowinguseractionsareallowed:
• ArmingorDisarmingofthearea(s)selectedfromtheARMorDISARMmenu
• AlarmSilenceforthearea(s)selected
• ZoneBypassofzonesassignedtothearea(s)selected
• ZoneMonitorofzoneassignedtothearea(s)selected
• Shiftschedulechangesallowedforthearea(s)selected
• ClosingCheckScheduleExtendisallowedforthearea(s)selected
EGRESS AREAS:
