DMP Electronics XR500 SERIES Programming Guide

XR500 Series Canadian Programming Guide Digital Monitoring Products
13
NETWORK OPTIONS
Network Options (XR500N/XR500E only)
NetworkOptionsareprovidedtodenethenetworkcongurationforthepanel.Thisinformationwillbe
used during communication of messages via network or email.
Note: IP addresses and port numbers may need to be assigned by the network administrator. When
enteringanIP,Gateway,orSubnetMaskaddressbesuretoenterall12digitsandleaveouttheperiods.
Forexample,IPaddress192.168.000.250isenteredas192168000250.
4.1
DHCP NO YES
DHCP Mode Enabled
If the panel uses a dynamic IP address select YES. When set to YES, the panel
operatesusingDHCPanddoesnotusetheLocalIPAddressnumber.WhentheDHCP
optionissettoNO,thepanelusestheIPaddressenteredinLocalIPAddress.The
default value for DHCP mode is YES.
4.2
LOCAL IP ADDRESS
Local IP Address
192.168.0.250
EnterthelocalIPaddress.TheLocalIPAddressmustbeuniqueandcannotbe
duplicated.ThedefaultlocalIPaddressis192.168.0.250.
4.3
GATEWAY ADDRESS
Gateway Address
192.168.0.1
Enterthelocalgatewayaddress.TheGatewayIPAddressisneededtoexityour
localnetwork.Thedefaultgatewayaddressis192.168.0.1.
4.4
SUBNET MASK
Subnet Mask
255.255.255.000
Enter the local subnet mask assigned to the panel. The default subnet mask address
is 255.255.255.000.
4.5
DNS SERVER
DNS Server
192.168.0.1
EntertheIPaddressoftheDNS(DomainNameSystem)usedbythepaneltoresolve
  domainnamesintoIPaddresses.Thedefaultaddressis192.168.0.1.
4.6
PASSPHRASE
-
Passphrase (XR500E only)
Toenableencryptiontypean8to16-characterPassphraseusingalphanumeric
characters. If you leave the Passphrase blank, the panel communicates with the
SCS-1RReceiver,butthedataisnotencrypted.ThePassphraseisblankbydefault.
TheXR500EpaneliscapableofcommunicatingencrypteddatatoanSCS-101
NetworkLineCardinstalledatthereceiver.TheXR500EpanelandtheSCS-101must
have the same secret password called a Passphrase.
Note: DO NOT LOSE THE PASSPHRASE. A lost or forgotten Passphrase requires that
theXR500EpanelandeveryiCOM-EunitreportingintothesameiCOM-Eunitatthe
receiver be individually reprogrammed with a new passphrase.
Note: An XR500E panel communicates using AES encryption. If you currently have
an XR500N panel installed, you may purchase a separate feature key to activate
encrypted communications using the Feature Upgrade process described in the
Feature Upgrade Section. Encrypted communication cannot be enabled on a
standard XR500 panel.
4.7
734N LISTEN
734N Listen Port
PORT: 2002
Entertheportnumberthatthe734N/734N-WiFiwillusetosendcommunicationto
the panel. This must be the same port that is programmed in Panel IP Port within
the734NCommunicationprogrammingmenu.
Note:The734NListenPortcannotbethesameasthepanelnetworkprogramming
port.
4.8
734N PASSPHRASE
734N Passphrase
-
Enteran8to16-characterPassphrasetoencryptcommunicationwiththe
734N/734N-WiFimodule.The734NPassphrasemustmatchthe734NPassphrase
enteredinCommunicationprogrammingofthe734N.ThePassphraseisblankby
default.
Note: A passphrase is required for operation.
