Digital Monitoring Products, Inc. XT Series Programming Guide
4
INTRODUCTION
1.7 Special Keys
The following special keys or areas are common to all DMP keypads.
CMD (Command) Key
Pressing CMD allows you to go forward through the programming menu and through each step of a
programming sec tion. As you go through the programming, the keypad display shows any current
programming already stored in the panel memory. If no change is required for an option, press CMD to
advance to the next step.
CMD is also used to enter information into the panel’s memory such as phone numbers or zone names.
Press CMD after entering information.
<— (Back Arrow) Key
Use the back arrow key to back up one step while programming. The back arrow key is also used when
an error is made while entering in formation. Press the back arrow key once to erase the last character
entered.
Select Keys or Areas
On LCD keypads, the top row of keys are called the select keys. On Graphic Touchscreen Keypads, the
keypad is sectioned into select areas. Each time you need to press a select key or area, the keypad
displays the function or options above one of the select keys or in the select area. Displaying choices
above individual select keys or in select areas allows them to be used for many different applications.
For example, you can enter AM or PM when programming the automatic test time or answer YES or NO
for a system option.
During programming, the select keys or areas also allow you to change infor mation currently in panel
memory by pressing the appropriate select key or area under or on the display. You then enter the new
information using the keypad data entry digit keys.
When there are more than four re sponse options avail able, press CMD to display the next one to four
options. Pressing the back arrow key allows you to review the previous four choices.
The select keys or areas are also used for choosing a section from the pro gramming menu. Press any
select key or touch the select area when the programming section name you want displays.
Note: For LCD Keypads, when instructed to press the rst select key, press the far left select key; the
second select key is the second from the left; third select key is second from the right; and the fourth
select key is the far right key. See Figures 6 and 7.
For Graphic Touchscreen Keypads, when instructed to press the rst select key, touch select area 1;
the second select key touch select area 2; third select key touch select area 3; and the fourth select
key touch select area 4.
