Digital Monitoring Products, Inc. XT Series Programming Guide
2
INTRODUCTION
Accessing the Programmer Menu
1. Connect the keypad to the PROG header.
2. If using a Wireless LCD Keypad, make sure panel communication has been established and the user
menu appears on an associated keypad before continuing.
3. Install the reset jumper across the two RESET pins on the panel for two seconds.
4. Remove the reset jumper and place it over just one pin for future use.
5. Enter the code 6653 (PROG). The keypad displays PROGRAMMER.
1.3 Programmer Menu
You are now ready to start programming the XT30/XT50 panel. Press CMD to scroll through the
programmer menu items listed below.
Menu Item Section in This Manual Menu Item Section in This Manual
Initialization 2 Bell Options 10
Communication 3 Output Options 11
Network Options 4 Output Information 12
Messaging Setup 5 Area Information 13
Device Setup 6 Zone Information 14
Remote Options 7 Stop 15
System Reports 8 Set Lockout Code 16
System Options 9 Appendix 17
Select a programmer menu item by pressing any select key or area when the name of that menu item
displays on the keypad. The detailed instructions for each programming step are found in this manual.
1.4 Programmer Lockout Codes
Although the XT30/XT50 panels allow you to access the Programmer menu without a lockout code, it is
recommended you program one to restrict programming access to authorized individuals only. See Set
Lockout Code.
Installing a lockout code
1. After entering the Programmer menu, the keypad displays PROGRAMMER. Press CMD until SET
LOCKOUT CODE displays (after STOP).
2. Press any select key or area. At ENTER CODE: -, enter a 1 to 5-digit lockout code. Press CMD.
3. At ENTER AGAIN, enter the same lockout code again and press CMD. The display shows CODE
CHANGED. The new code number must now be entered before the Programmer menu can be
accessed. The lockout code should be written down and kept in a secure place with access limited
to authorized persons only.
Lost Lockout Code requires factory reset: If you lose or forget the lockout code, the panel must
be sent back to the factory to be reset. There is no eld option for gaining access to the panel
without a valid lockout code.
