COMMUNICATION
Communication
3.1 Communication
The Communication section allows you to congure the communication settings for
the XT30/XT50 panel. After choosing the Communication Type, continue through the
list of options.
3.2 Account Number
Enter the account num ber sent to the receiver.
DD, NET, CELL - The range of account numbers for Digital Dialer, Network, and Cell
is 1 to 65535. For account numbers of four digits or less, you do not have to enter
leading zeros. The panel automatically right justies the account number.
CID - The account number range for this format is 1 - 9999.
3.3 Transmission Delay
Enter the number of seconds (15 to 45 seconds) the panel waits before sending
burglary alarm reports to the receiver. The bell and relay outputs are not delayed
during this period. Program Burglary Outputs for steady, and set Abort Reports to
YES if Opening and Closing reports are not being sent. Enter 0 (zero) to disable this
function. The default is 30.
If the area where the alarm occurred is disarmed during the Transmit Delay time,
only an Abort Report (S45) message is sent to the receiver. If the area where the
alarm occurred is disarmed after the alarm message is sent to the receiver but
before the Bell Cutoff time expires, even if the alarm was silenced, an Alarm
Cancelled (S49) message is sent. The Alarm Cancelled report cannot be disabled.
3.4 Communication Type
This species the communication method the panel uses to contact the receiver.
Press any select key or area to display the following communication options:
DD - Digital Dialer communication to DMP SCS-1R.
CID - Contact ID dialer communication to non-DMP receivers. This format sends the
report codes of the Ademco Contact ID communication format.
NET - Network communication to DMP Model SCS-1R Receivers or SCS-VR Receivers.
CELL - Cellular communication to DMP Model SCS-1R or SCS-VR Receivers.
WIFI - Network communication to DMP Model SCS-1R or SCS-VR Receivers.
NONE - For local systems. Selecting this ends communication programming.
Note: The Backup Dialer, Backup Cellular, Check-in Minutes, and Failed Minutes
options revert to their default values when the communication type is changed. All
other communication programming items remain at their programmed values.
3.5 Backup Dialer
Backup Dialer option is available if COMM TYPE is set for NET. The Backup Dialer
tries to send the message after the main communication fails for 60 seconds on NET.
If the backup dialer fails then the message is discarded.
3.6 Backup Cellular
Backup Cellular option is available if COMM TYPE is set for NET or DD/CID. The
Backup Cellular tries to send the message after the main communication fails for
60 seconds on NET and 10 dial attempts with DD/CID. If the backup dialer fails then
the message is discarded.
3.7 Test Time
Press COMMAND to enter the Test Time. Enter the time of day the panel sends the
test report to the SCS-1R Receiver. Use entries between 12:00 to 11:59 and then
choose AM or PM.
3.8 Test Days
Enter how often the panel test report is sent to the receiver for each
communication type programmed. Enter from 1 to 60 days. Enter zero to disable
the test report. Default is 1 (one) day. These options only display if a test time is
entered and that particular communication method is being used.
COMMUNICATION
ACCOUNT NO:
XMIT DELAY: 30
COMM TYPE: DD
DD CID NET CELL
WIFI NONE
BACKUP DIALER
NO YES
BACKUP CELL
NO YES
TEST TIME
00:00 AM PM
NET TEST DAYS: 1
DIAL TST DAYS: 1
CELL TST DAYS: 1
