XT Series Programming Guide Digital Monitoring Products, Inc.
25
OUTPUT OPTIONS
11.9 Begin Exit Output
This output/Favorite turns on any time an exit delay time starts. The output turns
off when the system arms or when the arming has been stopped. Enter 0 (zero) to
disable.
11.10 End Exit Output
This output/Favorite turns on any time an exit delay time ends. The output turns off
when the system disarms. Enter 0 (zero) to disable.
11.11 Ready Output
This output/Favorite turns on whenever all disarmed zones are in a normal state.
The output turns off when any disarmed zone is in a bad state. Enter 0 (zero) to
disable.
11.12 Armed Output
The entered output turns on any time the system is armed. The keypad display is
dependent on the system’s arming type.
For Home/Away systems, only the HOME and AWAY screens display. If a Bedroom area is
programmed into the panel, the SLEEP screen also displays. For All/Perimeter systems,
the ALL and PERIM screens display. For Area systems, the OUT screen displays. All options
are defaulted to 0 (zero). The output turns off when the system completely disarms.
Enter 0 (zero) to disable this output.
11.13 Disarmed Output
This output/Favorite turns on when all areas of the panel are disarmed. The output
turns off when an area is armed.
11.14 Burglary Output
This output/Favorite turns on any time a burglary zone goes into alarm. The output
turns off when the area in which the alarm occurred disarms and no other burglary
zones are in alarm. Enter 0 (zero) to disable this output.
11.15 Late To Close Output
Enter the output/Favorite to turn on at the expiration of a closing schedule when all
areas are not armed. The output activates simultaneously with the CLOSING TIME!
keypad display. The output is turned off when all areas are armed, the closing is
extended, or the schedule is changed.
11.16 Arm-Alarm Output
Enter the output/Favorite to turn on steady when any area of the system is armed.
If an alarm occurs causing the keypads to turn Red, this output pulses and continues
to pulse for approximately three (3) minutes after the panel is disarmed. Enter 0
(zero) to disable. Wireless Outputs:
• The Arm-Alarm Output is compatible with the Model 1117 Wireless LED
Annunciator and the Model 1116 Wireless Relay Output connected to a Model 572
Indicator LED.
• When the Model 1117 is battery operated, the LED is off when the system is
armed to conserve battery life. If an alarm occurs, the output ashes quickly.
• Using the Model 1116 connected to a Model 572, the LED is on when the system is
armed. If an alarm occurs, the output pulses.
• To operate the Arm-Alarm output within one second, program a fast response
number from 41 to 44. Fast response operation reduces overall wireless output
battery life.
• To operate the Arm-Alarm output within 15 seconds, program a slow response
number from 31 to 34. Slow response operation increases overall wireless output
battery life.
11.17 Heat Saver Temperature
Enter the desired temperature setting for all Z-Wave thermostats when the system
is armed ALL or AWAY. When the system is disarmed the thermostats return to their
previous settings. The range is 55-95 degrees. Enter 0 (zero) to disable.
11.18 Cool Saver Temperature
Enter the desired temperature setting for all Z-Wave thermostats when the system
is armed ALL or AWAY. When the system is disarmed the thermostats return to their
previous settings. The range is 55-95 degrees. Enter 0 (zero) to disable.
BEGIN EXIT: 0
END EXIT: 0
READY OUT: 0
ARMED SLEEP: 0
ARMED HOME: 0
ARMED AWAY: 0
ARMED ALL: 0
ARMED PERIM: 0
ARMED OUT: 0
DISARMED OUT: 0
BURGLARY OUT: 0
LATE CLS OUT: 0
ARM-ALARM OUT: 0
HEAT SAVER
TEMPERATURE: 0
COOL SAVER
TEMPERATURE: 0
