ZONE INFORMATION
14.12.2 Output Number
You can specify any of the outputs/Favorites on the XT30/XT50 to be activated by
a zone condition. The output/Favorite can be activated regardless of the report to
transmit or whether or not the zone is programmed as local. An output activated by
a non-24-hour armed zone is turned off when the zone’s area is disarmed by a user.
To enter an Output Number, press any select key or area followed by the output
number 1 to 4, 31-34, 41-44, or F1-F20. Press the COMMAND key.
14.12.3 Output Action
Entering an Output Number displays this option that allows you to assign an output
action to the relay. A description of the available output actions is given below:
STEADY - The output is turned on and remains on until the area is disarmed, an
output cutoff time expires, or the output is reset from the keypad User Menu.
PULSE - The output alternates one second on and one second off until the area is
disarmed, an output cutoff time expires, or the output is reset from the keypad
User Menu.
MOMENTARY - The output is turned on only once for one second.
FOLLOW - The output is turned on and remains on while the zone is in an off
normal, or bad condition. When the zone restores, the output is turned off.
After you have selected the Message To Transmit, the display prompts you for the
same three selections for Disarmed Short, Armed Open, and Armed Short conditions.
If the zone is a 24-hour type, only the Armed Open and Armed Short conditions
are displayed. When you have programmed all of the zone conditions, the Swinger
Bypass selection is then dis played.
14.13 Swinger Bypass
Selecting YES allows the zone to be swinger bypassed by the panel according to the
programming in Swinger Bypass Trips and Reset Swinger Bypass. The Bypassed zone
displays in the keypad Status List. Selecting NO disables swinger bypassing for this
zone.
How it works
If within one hour, a zone trips the total number of times as specied in Swinger
Bypass Trips, the panel bypasses it until the following conditions occur; the area
in which the zone is assigned is disarmed, the zone is manually reset through the
Bypass Zones keypad User Menu function, the zone remains normal for one hour and
the Reset Swinger Bypass is YES.
If the zone trips fewer than the specied times within one hour of the rst trip, the
bypass trip counter returns to 0 (zero) and the process must be repeated.
A report of the swinger bypass is sent to the receiver if Bypass Reports is YES.
14.14 Prewarn Address
Option is only shown for an Exit zone.
At the start of the entry delay, all keypad addresses dis play ENTER CODE: - . If you
want the prewarn to sound at all addresses, leave the default as shown.
To delete an address, press the matching number on the keypad. To disable
prewarning at all keypads, press a top row key to clear the addresses shown. Press
the COM MAND key when the address selection is com plete.
Note: On XT30 and XT50 systems, the prewarn tone stops at the keypad when the
rst digit of a user code is entered. If, within ve seconds, a valid user code is not
entered or an invalid user code is entered, the prewarn tone begins sounding again.
Fifteen seconds must elapse before entering a digit silences the prewarn tone again.
14.15 Entry Delay
Option is only shown for an Exit zone. Select the entry delay timer for this zone.
Entry delay timers 1 and 2 are programmed in Entry Delay in System Options.
OUTPUT NO: 0
ACTION:
STD PLS MOM FOLW
SWGR BYP NO YES
PREWARN:12345678
ENTRY DELAY: 1
