ZONE INFORMATION
TGL (Toggle) - The output alternates between the on state and off state. Each
button press toggles the output state.
OFF (Off) - The output is turned off. If programmed, the output was turned on by
some other means such as another button press, a zone action, or a schedule.
Note: When the output is assigned to PN/PN2 or EM/EM2 button action and is
turned on, the output turns off when any area is disarmed.
When the output action is steady, pulse or toggle and the output is turned on, the
output remains on until:
— the output cutoff time expires
— the output is reset from the keypad menu
— toggled off
Note: All wireless programming is stored in the XT30 or XT50 panel. When using the XT30, the 1100D,
1100DI, or 1100DH Wireless Receiver obtains the necessary programming information from the panel each
time the receiver powers up, when the programmer STOP routine is selected or the panel is reset. The
receiver memory refresh takes up to 45 seconds to complete depending on the number of wireless zones
programmed and the Red LED remains on during this time. Normal receiver operation is inhibited during
the memory refresh period.
14.11 Alarm Action
The Alarm Action section allows you to change or conrm the default alarm
characteristics of a zone type.
If you selected the non-24-hour zone type Blank, Night, Day, Exit, Auxiliary 1, or
Auxiliary 2, the Alarm Action programing begins with Disarmed Open.
If you selected the 24-hour zone type Fire, Panic, Emergency, or Supervisory, the
Alarm Action programming begins with Armed Open.
The Fire Verify zone type functions the same as Fire Type, with the following
exceptions: When a Fire Verify zone is placed into shorted condition, the panel
performs a Sensor Reset and does not send a report. If any Fire Verify or Fire zone
initiates an alarm within 120 seconds after the reset, an alarm is indicated. If an
alarm is initiated after 120 seconds, the cycle is repeated. If no other Fire Verify or
Fire zone is alarmed within 120 seconds, a zone fault report is sent to the receiver.
14.12 Disarmed Open
Denes the action taken by the panel when the zone is opened while the area is
disarmed. There are three actions to dene:
• Message to Transmit
• Output/Favorite Number
• Output Action
You must also make these selections for the Disarmed Short, Armed Open, and
Armed Short zone conditions. Press the COMMAND key to continue.
14.12.1 Message To Transmit
You can send two report types to the receiver: Alarm and Trouble. These are
represented by the characters A and T. Press any select key or area to display the
zone report options.
ALARM - Selecting A allows an alarm report to be sent to the receiver and the bell
output to activate according to zone type. See the Bell Action section. The zone
name appears in the panel’s alarmed zones status lists.
TROUBLE - Selecting T allows a trouble report to be sent to the receiver and the
zone name to appear in the panel’s alarmed zones status lists.
LOCAL - When you select L, an alarm report is NOT sent to the receiver. The bell
output still activates according to zone type and the zone name appears in the
panel’s alarmed zones status lists.
– (dash) - When you select – , reports are NOT sent to the receiver. The bell output
does not activate and there is no display in the panel’s alarmed zones status list.
Only the programmed Output Number activates.
OFF
ALARM ACTION . . .
DISARMED OPEN
MSG: TROUBLE
A T L -
To Next Page
