Digital Monitoring Products, Inc. XT Series Programming Guide
30
ZONE INFORMATION
ARM - When the zone is shorted, the programmed areas are armed. When restored
to normal, no action occurs. When the zone is opened from a normal (disarmed)
state, a trouble is reported. When opened from a shorted (armed) state, an alarm is
reported.
DIS (Disarm) - When programmed as an Area system, a short will disarm the
programmed areas. When programmed as a ALL/PERIM or HOME/AWAY system, a
short will disarm ALL areas. When restored to normal, no action occurs. When the
zone is opened from a normal (disarmed) state, a trouble is reported.
STEP - When programmed as an area system, a short will arm the areas and beep
the keypads once. When programmed as ALL/PERIM or HOME/AWAY, on the rst
short HOME will arm and beep the keypad once. On the second short, SLEEP will arm
and beep the keypads twice. On the third short, AWAY will arm and beep the keypad
three times. A normal condition will cause no action. An open condition will disarm
the programmed areas and beep the keypads for one second.
Note: This arming style is designed for wireless arming pendants. When using a
arming/disarming keyswitch, locate the keyswitch within the protected area.
MNT (Maintain) - When the zone is shorted, the programmed areas are armed.
When restored to normal, the programmed areas are disarmed and any alarm bells
are silenced. When the zone is opened from a normal (disarmed) state, a trouble
is reported. If opened from a shorted (armed) state, an alarm is reported and the
zone is disabled until you disarm the area(s) from either a keypad or Remote Link™
computer.
14.8 Next Zone
When YES is selected, the programming for the zone terminates and the display
returns to ZONE NO: - allowing you to enter a new zone number. Select NO to
program wireless devices or to make changes to the Alarm Action for a zone. The
Alarm Action is dened after 1100 Series Wireless Key Fob programming.
DMP Wireless
For 1100 series wireless operation, set the House Code from 1 to 50. See House Code programming in
System Options.
For an 1100 Series Key Fob see the 1100 Series Wireless Key Fob programming section.
Note: All wireless programming is stored in the XT30 or XT50 panel. The Wireless Receiver obtains
the necessary programming information from the panel each time the receiver powers up, when the
programmer STOP routine is selected or the panel is reset. The receiver memory refresh takes up to 45
seconds to complete depending on the number of wireless zones programmed and the Red LED remains on
during this time. Normal receiver operation is inhibited during the memory refresh period.
14.9 Wireless
Select YES to program this zone as a DMP wireless zone. You must program the
wireless House Code prior to adding wireless zones to the system. See House code
programming in System Options. Default is NO.
Note: For wireless zones 80-99 on the XT50, this option does not display. If a DMP
wireless House Code is not programmed, then NO HOUSE CODE displays.
14.9.1 Serial Number Entry
Enter the eight digit serial number, including leading zeros, found on the
wireless device.
Displays when the serial number is already programmed for another zone. The
programmed zone number displays.
14.9.2 Contact
This option displays if the serial number entered is for an 1101, 1102, 1103 or 1106
Universal Transmitter or 1114 Wireless Four-Zone Expander. Press any top row key to
select the contact.
Note: The 1102 Universal Transmitter only provides an external contact.
This option displays when programming an 1101, 1102, 1103 OR 1106 Transmitter.
Select INT to use the internal reed switch contacts. Select EXT to connect an
external device to the transmitter’s terminal block. Default is INTERNAL.
By allowing both of the Model 1101 or 1103 transmitter contacts (INT and EXT) to be
used at the same time, two zones may be programmed from one transmitter. When
using both contacts, you must use consecutive zone numbers.
MNT
NEXT ZN? NO YES
WIRELESS NO YES
SERIAL #: -
ALREADY USED Zxx
CONTACT: INTERNAL
INT EXT
To Next Page
