ZONE INFORMATION
For example, program transmitter serial number 01345678 as Zone 11 with an INT
contact type and Zone 12 with an EXT contact type. The same serial number is used
for both zones.
This option displays when programming an 1114 zone expander which provides four
input contacts. Press any top row key to select the contact. Default is Contact 1.
Select the contact number to program. The same transmitter serial number is used
for all four contacts. When using the contacts, use consecutive zone numbers.
For example, use serial number 08345678 to program Contact 1 for Zone 21,
Contact 2 for Zone 22, Contact 3 for zone 23, and Contact 4 for zone 24.
A tamper on the 1114 is transmitted as the zone number assigned to Contact 1.
This message displays when the Contact is already programmed for another zone.
The programmed zone number displays.
The Normally Open option only displays when EXT is selected as the Contact type.
For external devices connected to the 1101, 1102, 1103, or 1106 terminal block,
select NO to use normally closed (N/C) contacts. Select YES to use normally open
(N/O) contacts. Default is NO.
14.9.3 Supervision Time
Press any top row key to select the supervision time required for the wireless zone.
Press COMMAND to accept the default time. Default is 240 minutes.
Select the required number of minutes. The transmitter must check in at least
once during this time or a missing condition is indicated for that zone. 1100 Series
transmitters automatically checkin based on the supervision time selected for the
wireless zone, no additional programming is needed. If two zones share the same
transmitter, the last programmed supervision time is stored as the supervision time
for both zones. Zero (0) indicates an unsupervised transmitter.
The 3 minute supervision time is only available for zone types of Fire (FI), Fire
Verify (FV), and Supervisory (SV).
Note: When the panel is reset or a receiver is installed or powered down and
powered up, the supervision timer restarts for all wireless zones.
14.9.4 LED Operation
This only displays when programming a panic or pendant transmitter. Select YES to
turn a panic or pendant LED on during normal operation. Select NO to turn the LED
off during normal operation. The LED always operates on all transmitters when the
transmitter case is open and the tamper is faulted. Default is YES.
14.9.5 Disarm/Disable
Select YES to disable the Zone Tripped message from 1101/1102/1106 Universal
Transmitters (Version 108 or higher software), 1103 Universal Transmitters (Version
107 or higher), or 1126/1127 PIRs during the disarmed period. When disarmed, the
transmitter or PIR only sends Supervision, Tamper, and Low Battery messages to
extend transmitter battery life. For transmitters, a Zone Tripped message is sent
if the zone remains tripped for 20 seconds. Select NO to always send Zone Tripped
messages in addition to Supervision, Tamper, and Low Battery. Default is YES.
14.9.6 Wireless PIR Pulse Count
This option displays for 1126 and 1127 Wireless PIRs. Select the number of infrared
pulse counts (2 or 4) the PIR will use before sending a short message. The rst
infrared pulse starts a timer and count. If no additional infrared pulses occur in 25
seconds, the timer and count are reset. Default is 4.
14.9.7 Wireless PIR Sensitivity
This option displays for 1126 and 1127 Wireless PIRs. Select the sensitivity setting
for the PIR. Selecting LOW sets the PIR to operate at 75% sensitivity for installations
in harsh environments. Selecting HIGH sets the PIR to maximum sensitivity. Default
is LOW.
14.9.8 Next Zone
Select YES to return to the ZONE NO: - option to program a new zone. Select NO to
display the Alarm Action option.
CONTACT: 1
1 2 3 4
ALREADY USED Zxx
NORM OPEN NO YES
SUPRVSN TIME: XX
0 3 60 240
LED OPER NO YES
DISARM DISABLE
YES
WIRELESS PIR
PULSE COUNT: 4
WIRELESS PIR
SENSITIVITY: LOW
NEXT ZN NO YES
