Digital Monitoring Products, Inc. XT Series Programming Guide
28
ZONE INFORMATION
Zone Information
14.1 Zone Information
This allows you to dene the operation of each protection zone used in the system.
14.2 Zone Number
Enter the number of the zone you intend to program. Press COMMAND to enter a
zone name. Refer to the Enter Alpha Characters section.
Keypad Address Zone Numbers
1 11-14
2 21-24
3 31-34
4 41-44
5 51-54
6 61-64
7 71-74
8 81-84
Note: Use output numbers 31-34 (slow response) or 41-44 (fast
response) with 1100 Series Wireless output modules. Use zone
numbers 31-34 or 41-44 for DMP Series Key Fobs.
The XT50 (with the built-in 1100 Wireless Receiver) has 20 on-board wireless zones
numbered 80-99. The XT50 can be programmed to use zones 11-14, 21-24, 31-
34, etc. as wireless zones. Any keypad bus zone can be programmed as wireless
while the next consecutive zone number can be hardwired from a keypad or zone
expander.
Note: When using multi-zone wireless devices 1101, 1106, or 1114, do not use
consecutive zones 80-81.
14.3 Key Fob
Select YES to program an 1100 Series Key Fob for zones 31-34 or 41-44. When YES is
selected, programming continues at the 1100 Series Key Fobs Section. Default is NO.
14.4 Zone Name
Press any select key or area and enter up to 16 characters for the zone name. A
name must be given to each zone in the system. This name can be displayed at the
keypads when the zone is bad or viewed in Display Events. The zone name is also
sent to the receiver as part of a zone event report.
A zone that is not part of the system must be marked *UNUSED*. To mark a zone
unused, de lete the old name by pressing any select key or area, then press the
COMMAND key. The pro grammer auto matically pro grams the name as * UNUSED *. If
you selected ZONES? NO YES to clear the panel’s memory during Initialization, the
zones will already be marked * UNUSED *. See the Initialization section.
14.5 Zone Type
The Zone Type denes the panel’s response to the zone being opened or shorted.
Refer to the Appendix for zone type defaults and descriptions.
When you assign a Zone Type to a zone, responses are made automatically for
the zone. There are 11 Zone Types to choose from including Blank. The func tional
details of each response are described in Zone Type Defaults in the Appendix.
To select a new Zone Type, press any select key or area. The display lists the four
Zone Types shown below. When the Zone Type you want to select displays, press the
select key or area below the name.
Blank, Night, Day, or Exit. Press COMMAND to display additional zone types.
Fire, Panic, Emergency, or Supervisory. Press COMMAND to display additional zone
types.
Auxiliary 1, Auxiliary 2, Fire Verify, or Arming. Press the Back Arrow key to display
the previous zone types.
ZONE INFORMATION
ZONE NO: -
KEYFOB NO YES
* UNUSED *
ZONE TYPE: -
FI PN EM SV
A1 A2 FV AR
-- NT DY EX
