ZONE INFORMATION
If you select Blank, Night, Day, Exit, Auxiliary 1, or Auxiliary 2 as the Zone Type,
the zone must be assigned to an area. If you select Fire, Panic, Emergency, or
Supervisory as the Zone Type, these are 24-hour zones that are always armed and no
area assignment is needed. Press COMMAND to continue.
Caution: When a sensor reset is performed at the keypad, power will drop to
devices connected to zone 10 causing the panel to sense an open condition on all
zone types other than Fire (FI), Fire Verify (FV), and Supervisory (SV). Whenever
non-Fire and non-Supervisory zone types are used on zone 10, make the appropriate
adjustments to the zone Armed Action to prevent false alarms from occurring.
Refer to the Appendix for zone type specications and descriptions.
Note: For listed installations using wireless zones, do not use the FV zone type.
14.6 Area Assignment
For Area systems, enter the area number from 1 to 6 where this zone is being
assigned.
For All/Perimeter systems, choose INTERIOR or PERIMETER.
For Home/Away systems, choose INTERIOR, PERIMETER, or BEDROOMS
• INT (Interior) - Assigns the zone to area 2, Interior.
• BDRM (Bedroom)- Assigns the zone to area 3, Bedrooms. This option is only
displayed in Home/Away systems.
• PERIM (Perimeter) - Assigns the zone to area 1, Perimeter.
14.7 Arming Zone Assignment
For Area systems, this option species the areas to be armed by the Arming Type
zone. Press the appropriate number keys on the keypad to assign areas 1 to 6. When
disarmed, all programmed areas are disarmed.
For All/Perimeter systems, choose PERIM or ALL. For Home/Away systems, choose
HOME, SLEEP, or AWAY.
Perimeter/All - Specify whether the arming zone arms just the Perimeter (PERIM) or
the Perimeter and Interior areas (ALL) for All/Perimeter systems. When disarming,
all areas are disarmed.
HOME/SLEEP/AWAY - Specify whether the arming zone arms the Perimeter (HOME),
the Perimeter and Interior (SLEEP), or all three areas (AWAY). When disarming, all
areas are disarmed.
Arming zone operation
If a bad (faulted) Priority zone is in the area being armed by an Arming zone,
the arming is stopped. If there are no Priority zones, or they are all in a normal
condition, the following applies:
When a non-Priority zone is bad when an area is armed with a keyswitch on an
Arming zone, the arming is delayed for ve seconds. If, during the ve-second
delay, the keyswitch is turned to disarm, the arming stops. If the keyswitch is held
in the arming position for the full ve seconds, the bad zone is force armed and the
area is armed.
The ability to stop the arming does not apply if a wireless arming device is being
used. Refer to the Appendix.
Note: Arming from a zone, voice module, touch tone telephone, or Remote Link is
not affected by this operation.
14.7.1 Style
This option species the style for the arming/disarming operation. The default for
STYLE: is TGL (toggle). Pressing any select key or area displays the STYLE options.
To view more style options press the command key. The following is a description of
the action for each option condition.
TGL (Toggle) - When the zone changes from normal to shorted, the programmed
areas toggle between the armed or disarmed condition. When restored to normal,
no action occurs. When the zone is opened from a normal (disarmed) state, a
trouble is reported. When opened from a shorted (armed) state, an alarm is
reported and the zone is disabled until you disarm the area(s) from either a keypad
or Remote Link™ computer.
AREA NO: -
AREA: PERIMETER
INT BEDRM PERIM
AREA:
ARM AREA: PERIM
PERIM ALL
HOME SLEEP AWAY
STYLE: TOGGLE
TGL ARM DIS STEP
