BELL OPTIONS
Bell Options allows you to program the panel bell output functions. If using the Model 1135 Wireless Siren, the Trip with
Panel Bell option should be selected in the Output Information programming for the siren.
BELL CUTOFF TIME
Enter the maximum time from 1 to 15 minutes that a wireless output remains on. If the
output is manually silenced or the system is disarmed, the cuto time is reset. Default is
5.
AUTOMATIC BELL TEST
If YES is selected, the 1135 wireless siren turns on for two seconds when all areas in the
system are armed. The Bell Test only occurs when the areas are armed from a keypad.
Arming performed from an Arming zone or remotely from Remote Link™ does not
activate the Bell Test. The default is NO.
Closing Wait Operation
When Bell Test is set to YES, the closing wait function also operates. Closing Wait
provides a delay time before a monitored system arms until the panel receives an
acknowledgment of the closing report from the central station receiver. During the
delay, the keypad displays ONE MOMENT . . . Once the closing is acknowledged, the
keypad buzzes for one second and then displays ALL SYSTEM ON. If communication
fails, LOCAL ALARM ONLY displays.
BELL OUTPUT
Enter the output number (51-54, 61-64) for an 1116 or 1117 wireless output when needed
to follow the on and o condition of the bell action. Enter 0 (zero) to disable.
Note: When BELL ACTION below is set to T for Temporal Code 3, this Bell Output action
will be Pulse for wireless outputs 51-54 and 61-64.
BELL ACTION
Define the type of Bell Action from zone alarms that will occur. Trouble conditions do
not activate Bell Action. There are eight zone types you can program individually for
Bell Output. To provide a steady Bell Output, enter S. For a pulsed output, enter P. For
a Temporal Code 3 output, enter T. For a Temporal Code 4 output, enter 4. For no bell
action, enter N.
FIRE
Defines Bell Action for Fire Type Zones. The default is T.
BURGLARY
Defines Bell Action for Burglary Type Zones. The default is S.
SUPERVISORY
Defines Bell Action for Supervisory Type Zones. The default is N.
PANIC
Defines Bell Action for Panic Type Zones. The default is N.
EMERGENCY
Defines Bell Action for Emergency Type Zones. The default is set at N.
BELL CUTOFF: 5
BELL TEST NO YES
BELL OUTPUT: 0
BELL ACTION . . . . .
FIRE TYPE: T
BURGLARY TYPE: S
SUPRVSRY TYPE: N
PANIC TYPE: N
EMERGNCY TYPE: N
