AREA INFORMATION
This section allows you to assign functions to individual areas for XTLtouch panels. All non-24-hour zones must be
assigned to an active area. See the section on Zone Information. Activate an area by assigning it a name. A name is given
to each active area to assist the user during arming and disarming.
AREA TYPE
Enter the number of the area to program. In an area system, select from areas 1 to 6. In
an All/Perimeter system, select INTerior or PERIMeter. In a Home/Away system, select
INTerior, BDRM, or PERIMeter.
AREA NAME
In an area system, enter up to 16 characters for the area name. Only those areas given
names can have zones assigned to them. All others are marked *UNUSED*.
To add an area name to the system, press any select area and then enter up to 16
characters for the new name. Refer to the Entering Alpha Characters section. Press CMD
to continue.
To mark an active area as unused, delete the old name by pressing any select area then
press CMD. The panel automatically sets the name as *UNUSED*. If you have already
Initialized the panel, all areas will be marked as *UNUSED*.
BAD ZONES
At the time of automatic arming, some zones in the area may not be in a normal
condition. This option allows you to program the panel’s response to these bad zones.
This option is not displayed if AUTO ARM is NO.
BYP - All bad zones are bypassed. A report of the bypass is sent to the receiver if
Bypass Reports has been selected as YES. See the Bypass Reports section. The report
indicates SCH as the user number.
FORC - All bad zones are force armed. Zones force armed in a bad condition are capable
of restoring into the system and reporting alarms if tripped. A report of the force arm is
sent if Bypass Reports is YES. See the Bypass Reports section. The report indicates the
user number as SCH.
REF - The automatic arming is refused and no arming takes place. A No Closing report is
sent to the receiver regardless of the Closing Check selection.
Note: For listed installations, set Bad Zones to REF.
AUTOMATIC ARMING
Select YES to allow this area to arm automatically according to the opening and closing
schedule. If Closing Check is selected as YES, the automatic arming does not take place
until the expiration of a 10-minute Closing Check delay. If the area has been disarmed
outside a schedule, the Closing Check delay occurs one hour after the area is disarmed.
At arming, faulted zones are handled according to the option selected in Bad Zones. If
a Closing report is sent, the user number is indicated as SCH on the SCS-1R Receiver.
Select NO to disable automatic arming for this area. Default is NO.
AUTOMATIC DISARMING
Select NO to disable automatic disarming by schedule for this area. Select YES to allow
this area to automatically disarm according to a schedule. If an Opening report is sent to
the receiver, the user number is indicated as SCH.
INT BDRM PERIM
* UNUSED *
BAD ZONES: BYP
AUTO DIS NO
AUTO DIS NO YES
AUTO ARM NO YES
