OUTPUT OPTIONS
This section allows you to program output options for the 1116 and 1117 wireless outputs. Select from the following output
numbers: 51 to 54, 61 to 64, F01 to F20 (To Activate Z-Wave Favorites)
COMMUNICATION FAILURE OUTPUT
The Output/Favorite turns on when the panel fails to communicate with the receiver
after three communication attempts. Enter 0 (zero) to disable this output.
Note: To turn o the Communication Failure Output, disarm the panel or turn the output
o using the User Menu Outputs On/O function.
FIRE ALARM OUTPUT
This output turns on any time a fire type zone is placed in alarm. The output turns o
using the Sensor Reset option when no additional fire type zones are in alarm. Enter 0
(zero) to disable this output.
FIRE TROUBLE OUTPUT
This output/Favorite turns on any time a fire type zone is placed in trouble or when a
supervisory type zone is placed in alarm or trouble. The output turns
o when all fire and supervisory type zones restore to normal. Enter 0 (zero)
to disable.
PANIC ALARM OUTPUT
This output/Favorite turns on any time a Panic Zone (PN) is placed in alarm. The output
turns using the Sensor Reset option once all Panic Zones are restored. Enter 0 (zero) to
disabe this output. If a wireless output is programmed, the panel sends the Panic Test
Cadence or the Panic Alarm Cadence to the output when a Panic Test is performed or a
Panic Zone is placed in alarm.
AMBUSH OUTPUT
This output/Favorite turns on any time an Ambush code is entered at a keypad.
The output turns o using the Sensor Reset option. Enter 0 (zero) to disable
this output.
ENTRY OUTPUT
This output/Favorite turns on at the start of the entry delay time. The output turns o
when the area disarms or the entry delay time expires. Enter 0 (zero) to disable.
BEGIN EXIT OUTPUT
This output/Favorite turns on any time an exit delay time starts. The output turns o
when the system arms or when the arming has been stopped. Enter 0 (zero)
to disable.
END EXIT OUTPUT
This output/Favorite turns on any time an exit delay time ends. The output turns o
when the system disarms. Enter 0 (zero) to disable.
READY OUTPUT
This output/Favorite turns on whenever all disarmed zones are in a normal state. The
output turns o when any disarmed zone is in a bad state. Enter 0 (zero)
to disable.
ARMED HOME OUTPUT
The entered output turns on any time the system is armed. The keypad display is
dependent on the system’s arming type. For Home/Away systems, only the HOME and
COM FAIL OUT: 0
FIRE ALR OUT: 0
FIRE TRB OUT: 0
PANC ALM OUT: 0
AMBUSH OUT: 0
ENTRY OUT: 0
BEGIN EXIT: 0
END EXIT: 0
READY OUT: 0
ARMED HOME: 0
