AWAY screens display. If a Bedroom area is programmed into the panel, the SLEEP
screen also displays. For All/Perimeter systems, the ALL and PERIM screens display. For
Area systems, the OUT screen displays. All options are defaulted to 0 (zero). The output
turns o when the system completely disarms. Enter 0 (zero) to disable this output.
ARMED AWAY OUTPUT
This output/Favorite turns on when you select AWAY. All selected AWAY areas are
armed. The output turns o when the system is disarmed.
DISARMED OUTPUT
This output/Favorite turns on when all areas of the panel are disarmed. The output turns
o when an area is armed.
BURGLARY OUTPUT
This output/Favorite turns on any time a burglary zone goes into alarm. The output
turns o when the area in which the alarm occurred disarms and no other burglary
zones are in alarm. Enter 0 (zero) to disable this output.
ARM-ALARM OUTPUT
Enter the output/Favorite to turn on steady when any area of the system is armed. If
an alarm occurs causing the keypads to turn Red, this output pulses and continues to
pulse for approximately three (3) minutes after the panel is disarmed. Enter 0 (zero) to
disable.
Wireless Outputs
The Arm-Alarm Output is compatible with the Model 1117 Wireless LED Annunciator and
the Model 1116 Wireless Relay Output connected to a Model 572 Indicator LED.
When the Model 1117 is battery operated, the LED is o when the system is armed to
conserve battery life. If an alarm occurs, the output flashes quickly.
When using the Model 1116 connected to a Model 572, the LED is on when the system is
armed. If an alarm occurs, the output pulses.
To operate the Arm-Alarm output within one second, program a fast response number
from 61 to 64. Fast response operation reduces overall wireless output battery life.
To operate the Arm-Alarm output within 15 seconds, program a slow response number
from 51 to 54. Slow response operation increases overall wireless output battery life.
HEAT SAVER TEMPERATURE
Enter the desired temperature setting for all Z-Wave thermostats when the system
is armed ALL or AWAY. When the system is disarmed the thermostats return to their
previous settings. The range is 55-95 degrees. Enter 0 (zero) to disable.
COOL SAVER TEMPERATURE
Enter the desired temperature setting for all Z-Wave thermostats when the system
is armed ALL or AWAY. When the system is disarmed the thermostats return to their
previous settings. The range is 55-95 degrees. Enter 0 (zero) to disable.
CARBON MONOXIDE ALARM OUTPUT
This output turns on any time a Carbon Monoxide Zone (CO) is placed in alarm. The
output is turned o using Sensor Reset option while no additional CO type zones are in
alarm.
ZONE MONITOR OUTPUT
Defines Bell Action for Zone Monitor Zone Types. The default is set at N.
ARMED AWAY: 0
HEAT SAVER
TEMPERATURE: 0
COOL SAVER
TEMPERATURE: 0
BURGLARY OUT: 0
ARM-ALRM OUT: 0
DISARMED OUT: 0
OUTPUT OPTIONS
CO ALARM OUT: XXX
ZN MNTR TYPE: 4
