BUTTON ACTION
This option specifies the Button Action for an individual key fob button. The default
action for the button selected is displayed. Press any select area to display the Button
Action options. To view more options press CMD.
ARM (Arm) - Arms selected areas and force arms bad zones.
DIS (Disarm) - Disarms selected areas.
TGL (Toggle Arm) - Toggles arm/disarm for selected areas and force arms bad zones
when arming.
STA (Status) - Causes the key fob LED to indicate the arm/disarm status of the system.
CO (Carbon Monoxide) - For use with Carbon Monoxide Detectors.
PN (Panic) - Triggers a Panic zone type alarm with no restoral.
PN2 (Panic 2) - Triggers a Panic zone type alarm with no restoral when pressed
simultaneously with any other Panic 2 button. No action occurs when pressed alone.
EM (Emerg) - Triggers an Emergency zone type alarm with no restoral.
EM2 (Emerg 2) - Triggers an Emergency zone type alarm with no restoral when pressed
simultaneously with any other Emergency 2 button. No action occurs when pressed
alone.
OUT (Output) - Causes an output to turn on steady, pulse, momentary,
toggle or o.
RST (Sensor Reset) - Causes the panel to perform a standard Sensor Reset.
UN (Unused) - The button is not used and performs no action.
BUTTON PRESS TIME
This option specifies the amount of time (SHORT or LONG) the user must press the
button before the key fob sends a message to the wireless receiver. The default press
time displays. Press any select area to set the Button Press Time for Arm, Disarm,
Toggle, Status, Output, and Sensor Reset.
Note: The Button Press Time is not programmable on Panic (PN or PN2), Emergency
(EM or EM2) or Unused (UN) zones. For those zones the button press time is always two
(2) seconds.
SHORT - Press the button for one-half (1/2) second to send the message to the wireless
receiver.
LONG - Press the button for two (2) seconds to send the message to the
wireless receiver.
ARM/DISARM AREA SELECTION
For Area systems, enter the areas 1 to 6, to be armed/disarmed by the Key Fob button
being programmed.
This specifies the area to be armed by the Key Fob button being programmed.
For All/Perimeter systems, choose PERIM or ALL.
For Home/Sleep/Away or Home/Away systems, choose HOME, SLEEP, or AWAY.
After selecting the areas, for one-button key fobs the Zone No.: option displays. For
two-button or four-button key fobs, the Key Fob Button Selection option displays to
program additional buttons.
ARM DIS TGL STA
PN PN2 EM EM2
OUT RST UN
PRESS TIME: XXXXX
SHORT LONG
AREA: 1 2 3 4 5 6
ARM AREAS: PERIM
ACTION: XXXXXXX
CO
