OUTPUT NUMBER
You can specify a wireless output to operate when OUT (Output), PN (Panic), PN2
(Panic 2), EM (Emergency), or EM2 (Emergency 2) is selected for a key fob Button
Action and the button is pressed. Valid range is 51-54, 61-64, and F1-F20. For an output
turned on by a PN, PN2, EM, or EM2 button action, the output turns o when any area
is disarmed. To enter an output number, press any select area followed by the output
number. Press CMD.
OUTPUT ACTION
This option allows you to define the output action (STD, PLS, MOM, TGL, OFF) for the
selected output number. The default is Steady.
STD (Steady) - The output is turned on and remains on.
PLS (Pulse) - The output alternates one second on and one second o.
MOM (Momentary) - The output is turned on only once for one second.
TGL (Toggle) - The output alternates between the on state and o state. Each button
press toggles the output state.
OFF (O) - The output is turned o. If programmed, the output was turned on by some
other means such as another button press, a zone action, or a schedule.
Note: When the output is assigned to PN/PN2 or EM/EM2 button action and is turned
on, the output turns o when any area is disarmed. When the output action is steady,
pulse or toggle and the output is turned on, the output remains on until:— the output
cuto time expires— the output is reset from the keypad menu— toggled o
ALARM ACTION
The Alarm Action section allows you to change or confirm the default alarm
characteristics of a zone type.
If you selected the non-24-hour zone type Blank, Night, Day, Exit, Auxiliary 1, or Auxiliary
2, or Doorbell, the Alarm Action programming begins with Disarmed Open.
If you selected the 24-hour zone type Fire, Panic, Emergency, Supervisory, or CO, the
Alarm Action programming begins with Armed Open.
DISARMED OPEN
Defines the action taken by the panel when the zone is opened while the area is
disarmed. There are three actions to define:
Message to Transmit
Output Number
Output Action
You must also make these selections for the Disarmed Short, Armed Open, and Armed
Short zone conditions. Press CMD to continue.
OUTPUT NO: 0
ACTION:
STD PLS MOM TGL
OFF
DIARMED OPEN
ALARM ACTION . . .
