30 XTLtouch Series Programming Guide | Digital Monitoring Products
DMP Wireless
For wireless key fob programming see the 1144 Series Key Fob section. Note: All wireless programming is stored in the
XTLtouch panel. Each time the panel powers up, when the programmer STOP routine is selected or the panel is reset, the
wireless receiver memory refresh could take up to 45 seconds to complete depending on the number of wireless zones
programmed and the Red LED remains on during this time. Normal wireless receiver operation is inhibited during the
memory refresh period. If using a 738T, follow the installation steps listed in the 738T Wireless Translator Installation
Guide. (https://buy.dmp.com/dmp/products/documents/LT-1760.pdf)
SERIAL NUMBER ENTRY
Enter the eight digit serial number, including leading zeros, found on the
wireless device.
CONTACT
This option displays if the serial number entered is for an 1101, 1103, or 1106 Universal
Transmitter or 1114 Wireless Four-Zone Expander. Press any top row key to select the
contact.
This option displays when programming an 1101, 1103, or 1106 Universal Transmitter.
Select INT to use the internal reed switch contacts. Select EXT to connect an external
device to the 1101, 1103, or 1106 terminal block. Default is INTERNAL.
By allowing both of the transmitter contacts (INT and EXT) to be used at the same time,
two zones may be programmed from one transmitter. When using multiple contacts, you
must use consecutive zone numbers.
For example, program transmitter serial number 01345678 as Zone 11 with an INT
contact type and Zone 12 with an EXT contact type. The same serial number is used for
both zones.
This option displays when programming an 1114 zone expander which provides four
input contacts. Press any top row key to select the contact. Default is Contact 1.
Select the contact number to program. The same transmitter serial number is used for
all four contacts. When using the contacts, you must use consecutive zone numbers.
For example, use serial number 08345678 to program Contact 1 for Zone 21, Contact 2
for Zone 22, Contact 3 for zone 23, and Contact 4 for zone 24.
A tamper on the 1114 is transmitted as the zone number assigned to Contact 1.
This message displays when the Contact is already programmed for another zone. The
programmed zone number displays.
The Normally Open option only displays when EXT is selected as the Contact type. For
external devices connected to the 1101 terminal block, select NO to use normally closed
(N/C) contacts. Select YES to use normally open (N/O) contacts. Default is NO.
SUPERVISION TIME
Press any top row key to select the supervision time required for the wireless zone. Press
CMD to accept the default time. Default is 240 minutes. Select the required number
of minutes. The transmitter must check in at least once during this time or a missing
condition is indicated for that zone. 1100 Series transmitters automatically check in
based on the supervision time selected for the wireless zone, no additional programming
is needed. If two zones share the same transmitter, the last programmed supervision
time is stored as the supervision time for both zones. Zero (0) indicates an unsupervised
transmitter. The 3 minute supervision time is only available for zone types of Fire (FI),
Fire Verify (FV), Supervisory (SV), and Carbon Monoxide (CO).
Note: When the panel is reset the supervision timer restarts for all wireless zones.
SERIAL #: -
SUPRVSN TIME: 0
0 60 240
INT EXT
