Following are the Dolby CP950/CP950A pinouts for analog output channels 9-16:
Table 7: Analog output 2 channels 9‑16 pinouts
Pin Description
1 Channel 16 +
2 Channel 16 ground
3 Channel 15 -
4 Channel 14 +
5 Channel 14 ground
6 Channel 13 -
7 Channel 12 +
8 Channel 12 ground
9 Channel 11 -
10 Channel 10 +
11 Channel 10 ground
12 Channel 9 -
13 Empty
14 Channel 16 -
15 Channel 15 +
16 Channel 15 ground
17 Channel 14 -
18 Channel 13 +
19 Channel 13 ground
20 Channel 12 -
21 Channel 11 +
22 Channel 11 ground
23 Channel 10 -
24 Channel 9 +
25 Channel 9 ground
Dolby CP950 and CP950A 16-Channel analog outputs
