Table 2: CP950A CAT1741 LED indicators LEDs
LED Color State
POWER Amber
Green
Red
Booting
Booted successfully
Problem: Stop using the unit. (power
down, reseat the unit and try again. If
the problem persists, contact
support).
ACTIVITY Amber
Green or int
ermittently flashing green
Booting
Booted successfully and running OK
STATUS (security) Amber
Green
R
ed
Booting
Booted successfully
Security error, such as tamper or
security processor error. Unit cannot
play Dolby Atmos.
1.3.3 CAT1740 and CAT1741 AC input
The CP950 uses a CAT1740 power supply module to supply power to the unit. The input is a simple
unswitched IEC power inlet module that is typically used in computers. The CAT1740 power supply supports
100-240 VAC and draws 0.64-0.30 Amps. The CAT1740 supports alternating current frequency between 50-60
Hz. If needed, a CAT1741 could power a regular CP950. The CP950A uses a CAT1741 power supply module to
supply power to the unit. The input is a simple unswitched IEC power inlet module that is typically used in
computers. The CAT1741 power supply supports 100-240 VAC and draws 1.2-0.6 Amps. The CAT1741 supports
alternating current frequency between 50-60 Hz. The CAT1741 is the only power supply that works with a
CP950A. You cannot use a CAT1740 in a CP950A.
1.4 Contacting Dolby
You can contact Dolby Cinema Solutions and Support using email or regional telephone numbers. You can
also access documentation by visiting the Dolby customer portal.
Contact Dolby Cinema Solutions and Support
• Send an email to cinemasupport@dolby.com.
• Call:
AMERICAS: +1-415-645-4900
ASIA, CHINA, and PACIFIC RIM: +86-10-800-320-0128
EMEA: +44-33-0808-7700
JAPAN: +81-3-4520-9798
Access documentation
Visit https://customer.dolby.com.
Submit feedback about this documentation
Send an email to documentation@dolby.com.
Contacting Dolby
Dolby Cinema Processor CP950 and Dolby Atmos Cinema Processor CP950A Manual 23
Issue 9 Part Number 8800298 19 January 2022
