7.1 Dolby DSS200 with CAT862 MB 8 x AES output pinouts
This table provides the Dolby DSS200 (with CAT862) 8 × AES output pinouts and descriptions.
Table 11: DSS200 8 x AES output pinouts
Pin Description
1 Advanced Encryption Standard (AES) Common
2 Channels 1/2 -
3 Channels 3/4 +
4 AES Common
5 Channels 5/6 -
6 Channels 7/8 +
7 AES Common
8 Channels 9/10 +
9 AES Common
10 Channels 11/12 -
11 Channels 13/14 +
12 AES Common
13 Channels 15/16 -
14 Channels 1/2 +
15 AES Common
16 Channels 3/4 -
17 Channels 5/6 +
18 AES Common
19 Channels 7/8 -
20 AES Common
21 Channels 9/10 -
22 Channels 11/12 +
23 AES Common
24 Channels 13/14 -
25 Channels 15/16 +
Dolby DSS200 with CAT862 MB 8 x AES output pinouts
Dolby Cinema Processor CP950 and Dolby Atmos Cinema Processor CP950A Manual 145
Issue 9 Part Number 8800298 19 January 2022
