(3) Remove the piston ring with a plier.
(4) Clean the piston thoroughly.
3.1.32 Cylinder liner
Diassemble the cylinder liner with a special tool or hand
but be careful not to generate any damage at cylinder
block.
3.1.33 Cam shaft gear and idle gear
Unscrew the camshaft gear fixing bolts and remove the
camshaft gear.
SPC000006 5ton Diesel Engine
Page 40
