1.1.1.2 REASSEMBLY
see also illustrated Tables,
Page 26 !
NOTE :
Check all components for damage and renew if
necessary !
Check free travel of the moving parts in the housing
prior to the installation !
Spools can be exchanged individually !
Oil components prior to the reassembly !
Introduce detent blocks (1 and 2) into the bores and
fix them by means of stop plates (3 and 4).
Install stop plate (5).
NOTE ;
Pay attention to the installation position of the
various stop plates, see Figure on the right !
SPC000007 Transmission and Torque Converter
Page 18
