Assemble 1st gasket, intermediate plate and 2nd
gasket.
NOTE :
Pay attention to the various gaskets, see
corresponding Spare Parts List !
Place control unit against shoulder until contact is
obtained and fasten it by means of hex. head
screws (mount flat washers).
Torque limit 20 Nm
Install deliver/ lines according to the Illustration in
the Spare Parts List !
NOTE ;
Mount new sealing rings !
SPC000007 Transmission and Torque Converter
Page 34
