2. TORQUE CONVERTER
VersionWith converter connecting
clutch (WK)
2.1 DISASSEMBLY
Separate the complete converter from the
transmission by means of lifting device.
(S) Assembly car compl. with tilting device
5870 350 000
(S) Basic support 5870 350 014
(S) Support 5870 350 036
(S) Set of eye bolts 5870 204 002
Loosen screwed connection.
Install hex. head screw, tap impeller wheel loose
and separate it from converter impeller cover, see
Figure !
Loosen hex. head screws and remove impeller
wheel flange.
Transmission and Torque Converter SPC000007
Page 75
Figure 1
Figure 2
Figure 3
Figure 4
