Press free wheel inner ring out of the stator and
remove released components.
Squeeze out snap ring.
Press free wheel outer ring out of the stator.
Separate turbine wheel from converter impeller
cover.
SPC000007 Transmission and Torque Converter
Page 76
Figure 5
Figure 6
Figure 7
Figure 8
