Loosen hex. head screws, remove backing plate
and plate pack.
Remove cup spring and demount all driving pins
(Arrow).
Separate piston from converter impeller cover by
means of compressed air.
( S ) Rubber cap 5870 509 009
Press profiled bush out of the converter impeller
cover.
NOTE ;
The profiled bush is axially fixed by means of a snap
ring which will be destroyed at the pressing out. !
Transmission and Torque Converter SPC000007
Page 77
