Fasten both plates by means of hex, head screws
(install flat washers).
Torque limit (M8/8.8) 23 Nm
NOTE :
Secure hex. head screws with Loctite (Type-No.
270).
Squeeze in circlip 8.
( S ) Clamping pliers 5870 900 021
Press the speedometer-drive worm against shoulder.
NOTE :
In case of a Version without mechanical
speedometer, a spacer has to be installed instead of
the speedometer-drive worm !
Thread up output shaft 9 until contact is obtained.
\
SPC000007 Transmission and Torque Converter
Page 108
Figure 103
Figure 102
Figure 100
Figure 101
