Press ball bearing out of the housing bore.
6.1.2 REASSEMBLY
Press ball bearing against shoulder until contact is
obtained.
Fix ball bearing by means of circlip and lay sleeve
upon it.
Install shaft seal with the sealing lip lacing the oil
chamber.
NOTE ;
By application of the prescribed driver, the exact
installation position is obtained !
If the outer diameter of the shaft seal is rubberized,
wet the sealing surface with spirit!
If not, use a sealing compound !
Grease sealing lip !
( S ) Driver 5870 048 134
Transmission and Torque Converter SPC000007
Page 193
