17. Dismantle main drive assembly
Dismantle connection bolts between main drive and
shell assembly, take out main drive with jackscrew,
and suspend main drive assembly.
Note: When suspending main drive assembly,
guarantee suspending and dismantling tools are at
the above of main drive assembly to avoid spare
parts inside are knocked again during suspending
and dismantling process.
Front Axle SPC000009
Page 17
