Doosan DISD SD 310 - Page 598

Detailed list of spare parts
Reference Number
Description
Reference Number
Description
1
Cross Link block
12
Stator
2
Front cover
13
O-Ring
3
Valve body
14
Spacer Plate
4
Spring lamination
15
Steel Ball
5
Pin
16
Big Baffle Rring
6
Valve bush
17
Thrust Ball Bearing
7
Valve spool
18
Small Baffle Ring
8
Linkage Shaft
19
O-Ring
9
Rotor
20
X-Ring
10
Limited Post
20
O-Ring
11
Rear Cover
SPC000017 Steering Unit
Page 4
Figure 2
