Doosan DISD SD 310 - Page 677

Function
Display
Sensor Specification
Input Terminal
Input Specification
Torque
Converter Oil
Temperature
Meter
CN-09
098.96KΩ
602.476KΩ
801.25KΩ
1000.6744KΩ
1200.4071KΩ
Engine Coolant
Temperature
Gauge
CN-02
098.96KΩ
405.312KΩ
602.476KΩ
801.25KΩ
1000.6744KΩ
1200.4071KΩ
Hour meter
Speedometer
Odometer
CN-04
CN-27
Engine oil
pressure
meter
CN-08
0.1MPa——0.9V
0.2MPa——1.3V
0.3MPa——1.7V
0.4MPa——2.1V
Electrical System SPC000025
Page 17
