Doosan H2017 Installation Manual

27
2.5 Robot Specifications
2.5.1 Basic Specification
Model Name
M0609
M0617
M1013
M1509
H2017
H2515
Weight
27 kg
34 kg
33 kg
32 kg
74 kg
72 kg
Payload within
Work Radius
6 kg
6 kg
10 kg
15 kg
20 kg
25 kg
Max. Work Radi
us
900 mm
1700 mm
1300 mm
900 mm
1700mm
1500mm
Number of Axe
s
6
Max. TCP Spee
d
Over 1 m/s
Position Repeat
ability (ISO 928
3)
±0.1 mm
(±0.03 mm)
±0.1 mm
±0.1 mm
(±0.05 mm)
±0.1 mm
(±0.03 mm)
±0.1 mm
Protection Ratin
g
IP 54
Noise
< 65 dB
Installation Dire
ction
Floor / Wall / Ceiling
Floor Only
Controller and
Teaching Penda
nt
Doosan Controller & TP
Vibration and A
cceleration
10≤f< 57㎐ - 0.075mm amplitude
57≤f≤150㎐ – 1G
Impact
Max Amplitude : 50㎨(5G)
* Time :30㎳ , Pluse : 3 of 3 (X,Y,Z)
Operating Temp
erature
0 ℃ ~45 ℃ (273K to 318K)
Storage Temper
ature
-5 ℃ ~50 ℃ (268K to 323K)
Humidity
20%~80%
