Issued June 2020
Compressed Natural Gas (CNG) Option
Copyright 2020, Heil Environmental
Printed in U.S.A.
251
HEIL CNr
(CONTINUED)
Ignition Power OFF
The display notification shown in the figure below will only
does not have Ignition Power. This Alarm can be beneficial
in the event that all Tank Solenoids Valves have failed to
open due to the loss of Ignition Power, which is required to
open the Tank Solenoids Valves.
Figure 94. Display Screenshot:
Ignition Power OFF
System Over Voltage
The display notification shown in the figure below will only
be displayed in the event that the System Voltage is greater
than 36 volts for 10 seconds, indicating that there is voltage
too high to safely operate the Cortex Controller and
Display.
Figure 95. Display Screenshot:
System Over Voltage
