Dräger Babyleo TN500 - 14.4 Measured Value Display

190 Instructions for use Babyleo TN500 SW 1.0n
Technical data
Radiant warmer operation
Radiant flux per area in highest horizontal mat-
tress tray position
At 30% radiant warmer power 10 mW/cm
2
At 60% radiant warmer power 18 mW/cm
2
At 100% radiant warmer power 32 mW/cm
2
Minimum ceiling clearance To ensure safe operation of the radiant warmer,
maintain a distance of at least 20 cm (8 in)
between the upper edge of the radiant warmer
and the ceiling
Incubator operation
Warm-up time 15 to 20 minutes
Humidification Boiling of Aquadest/distilled water
Flow velocity over mattress surface 10 cm/s (3.94 in/s) (with a horizontal mattress
tray and an air temperature of 36 °C (96.8 °F))
Maximum CO
2 concentration in the incubator
measured in accordance with IEC 60601-2-19
<0.5 Vol%
Fresh air filter The fresh air filter is located in the rear of the
sensor wall.
14.4 Measured value display
Radiant warmer
Setting range Off, 10 % to 100 %
Pre-warm mode 100 % for 3 minutes
60 % for 11.5 minutes
30 % until setting is changed
Air temperature regulation
Measurement principle NTC, 2 x
Measurement range 13 to 45 °C (55.4 to 113 °F)
Measurement uncertainty ±0.8 °C (1.44 °F)
Setting range 20 to 39 °C (68 to 102.2 °F)
<28 °C (82.4 °F), after confirmation
>37 °C (98.6 °F), after confirmation
Skin temperature regulation
Measurement principle NTC
Measurement range 13 to 43 °C (55.4 to 109.4 °F)
Sensor Only use original Dräger skin temperature sen-
sors.
Measurement uncertainty (sensors) ± 0.1 °C (0.18 °F)
Measurement uncertainty (entire system) ±0.3 °C (0.54 °F)
14.3 Performance characteristics (continued)
