rider seat (low mode)
Configure the rear toothing (A) and central rubber
blocks (B) as shown (Fig 13), checking that the rubber
blocks (B) are locked in place by the rubber band (C).
Position the rider seat (4) on the vehicle, making sure
to correctly fit it into the lower of guides (5).
Have rider seat and passenger seat in high or
low mode correctly configured by a Ducati Dealer or
authorised Service Centre.
Fig 13
Fig 14
39
