rider seat (high mode)
Configure the rear toothing (A) and release central
rubber blocks (B) from rubber band (C), turning them
outwards as shown (Fig 13), securing unused rubber
band (C).
Position the rider seat (4) on the vehicle, making sure
to correctly fit it into the upper of guides (5).
Have rider seat and passenger seat in high or
low mode correctly configured by a Ducati Dealer or
authorised Service Centre.
Fig 15
Fig 16
40
