Information (Info)
This Function allows viewing the vehicle battery
voltage and the RPM "digital" indication.
Enter the SETTING MENU.
Select "Info" option, by pressing button (1) or (2).
Once function is highlighted, press button (4).
When entering this function, the instrument panel
displays:
- “Battery” with battery voltage value;
- "rpm" with the number of engine rpm in digital
format.
To exit the menu and go back to previous page
highlight the "
Back" indication and press button
(4).
"Battery" information is displayed as follows:
- if the battery voltage is equal to or lower than 10.9
V, the "LOW" message will be displayed in red and
flashing;
- if battery voltage is between 11.0 V and 11.7 V the
reading will be displayed in red and flashing;
- if battery voltage is between 11.8 V and 14.9 V the
reading will be displayed steadily with the battery
icon on a standard background;
DRL
Turn indicators
Info
Exit
42
1
Fig. 147
Battery
rpm
14,3 volt
15.000
...
Back
42
1
Fig. 148
