Tank filler plug
Opening
Lift flap (1) and insert the key in the lock. Turn the key
clockwise by 1/4 of a turn to release the lock.
Lift the plug (2).
Closing
Close the plug (2) with the key inserted and push it
down into its seat. Remove the key and close flap (1)
protecting the lock.
Note
Plug can only be closed when key is inserted.
Warning
After refuelling, always make sure that the plug
is perfectly in place and closed.
Fig. 203
Fig. 204
247
