Seat lock
Opening
Insert the key into the seat lock (1) and turn it until the
passenger seat (2) catch disengages with an audible
click.
Pull the passenger seat (2) towards the front end of
the motorcycle until releasing it.
Closing
Insert the passenger seat (2) from the side and push
it towards the rear end of the motorcycle until fully
home.
Warning
To close the seat cover insert it from the
motorcycle side and slide it towards the rear side until
hearing the engagement click.
Fig. 205
Fig. 206
248
