Checking coolant level and topping up, if
necessary
Check that coolant in the expansion reservoir is
between the MIN (1) and MAX (2) marks on the
visible sticker by removing the right half-fairing.
Top up if the level is below the MIN mark.
Important
Have the top-up performed at a Ducati Dealer or
Authorised Service Centre.
Warning
Place the motorcycle upright on a flat surface
and make sure the engine is cold before proceeding.
Fig. 223
275
