Checking drive chain tension
Important
Have chain tension adjusted by a Ducati Dealer
or authorised Service Centre.
Make the rear wheel turn until you find the position
where chain is tightest. Set the motorcycle on the
side stand. With just a finger, push down the chain at
the point of measurement and release.
Measure the distance (A) between the centre of the
chain pins and the plastic section of the chain sliding
shoe. It must be: A = 23 ÷ 25 mm (0.90 ÷ 0.98 in).
Important
This only applies to the motorcycle STANDARD
settings, available upon delivery.
Fig. 241
288
