Ducati PANIGALE V4 - Warnings and Alarms

Warnings/Alarms (WARNING)
The instrument panel manages a number of
warnings / alarms, aimed at giving useful information
to the rider during use.
Upon Key-On, if there are any active warnings, the
instrument panel displays the present warnings.
During normal use, whenever a warning is triggered,
the instrument panel automatically displays the
warning. Whenever a warning is triggered, it is
displayed for 3 seconds in a (well-visible icon) "large"
size and then continues being displayed in the small
size ("small" icon).
If several warnings are active, the corresponding
icons will be displayed one after the other, each
remaining on display for 3 seconds.
0
11:34
A.M.
SPORT
RPM X 1000
Gear
km/h
N
10
9
8
7
6
5
4
3
2
1
11
12
13
14
15
DTC 2
DQS OFF
DWC 8
SETTING MENU
TRIP 1
0.0 km
TOT km
1245
LO HI
11:34
A.M.
SPORT
RPM X 1000
Gear
km/h
N
10
9
8
7
6
5
4
3
2
1
11
12
13
14
15
DTC 2
DQS OFF
DWC 8
0
ICE
LO HI
Fig. 167
211
