Note
This is the procedure specified by Italian
regulations for checking the maximum height of the
light beam. Please adapt said procedure to the
provisions in force in your own country.
To align the headlight beam, turn the screws (1) and
(2) located at the front of the vehicle, on both sides.
Screw (1), positioned on the left side, acts on the high
beam:
- turn clockwise to lower the light beam;
- turn counter clockwise to raise the light beam.
Screw (2), positioned on the right side, acts on the
low beam:
- turn clockwise to lower the light beam;
- turn counter clockwise to raise the light beam.
Warning
The headlight might fog up if the motorcycle is
used under the rain or after washing. Switch headlight
on for a short time to dry up any condensate.
Fig. 245
Fig. 246
293
