Duplo DSC-10/20 User Manual

5-5
Chapter 5 Troubleshooting Guide
Message Icon Cause Countermeasures Reference
Jam-Remain at
Stacker
Paper jammed at the paper
ejection outlet of the paper
receiving table at start or
during operations.
Eject the jammed paper by pressing the
key. If paper is not ejected even if the key
is touched, open the vertical conveyance board
and remove the jammed paper by hand. (For
details on how to pull out the paper, refer to
the page indicated.) Remove all paper from the
paper receiving table when performing sorting
operations on the ejection stacker. Touch the
key to resume operations.
P.5-10
Paper jammed at the paper
ejection outlet of the paper
receiving table at preset.
Eject the jammed paper by pressing the
key. If paper is not ejected even if the key is
touched, open the vertical conveyance board and
remove the jammed paper by hand. (For details
on how to pull out the paper, refer to the page
indicated.) Press the key again.
P.5-10
Jam-No Paper
at LUL-HM In-
feed
Paper jammed before the
paper reached the LUL-HM
conveyance inlet, or reached
the inlet late.
Eject the jammed paper by pressing the
key. If paper is not ejected even if the key
is touched, open the vertical conveyance board
and remove the jammed paper by hand. (For
details on how to pull out the paper, refer to
the page indicated.) Remove all paper from the
paper receiving table when performing sorting
operations on the ejection stacker. Touch the
key to resume operations.
P.5-10
Paper is not sent from the
paper feed unit to the LUL-HM
conveyance inlet.
If paper is not sent due to miss feed or because
there is no paper, refer to the countermeasure
provided for paper feed bin errors. Touch the
key to resume operations.
—
Jam-Remain at
LUL-HM Infeed
Paper jammed at the LUL-HM
conveyance inlet at start or
during operations.
Eject the jammed paper by pressing the
key. If paper is not ejected even if the key
is touched, open the conveyance board of the
LUL-HM and remove the jammed paper by hand.
(For details on how to pull out the paper, refer to
the page indicated.) Touch the key to restart
operations.
P.5-10
Paper jammed at the LUL-HM
conveyance inlet at preset.
Eject the jammed paper by pressing the
key. If paper is not ejected even if the key is
touched, open the conveyance board of the LUL-
HM and remove the jammed paper by hand. (For
details on how to pull out the paper, refer to the
page indicated.) Press the key again.
P.5-10
Jam-No Paper
at LUL-HM
Eject
Paper jammed before reaching
the LUL-HM ejection outlet, or
reached it late.
Eject the jammed paper by pressing the
key. If paper is not ejected even if the key
is touched, open the conveyance board of the
LUL-HM and remove the jammed paper by hand.
(For details on how to pull out the paper, refer to
the page indicated.) Touch the key to restart
operations.
P.5-10
