Technical Specifications
Operating Instructions 878-M PREMIUM - 02.0 - 02/2018 9
2.4Technical data
2.4.1 Data overview by subclasses
Subclasses: 878-M PREMIUM
-160722-M
-260722-M
Stitch type Double lockstitch 301
Hook type Vertical hook,
large (L)
Number of needles 1
2
Needle system 134
Needle strength [Nm] 70 - 160
Maximum thread strength [Nm] 120/3 - 10/3
Stitch length, forwards / backwards
[mm]
7/7
Maximum s.p.m. [min
-1
] according to
stitch length [mm]
2500/0-3.5; 2300/3.6-4; 2100/4.1-4.5; 2000/4.6-5;
1800/5.1-6; 1600/6.1-6.5; 1500/6.6-7
Maximum sewing foot stroke [mm] 13
Maximum stroke height [mm] 8
Mains voltage [V] 230
Mains frequency [Hz] 50 / 60
Length/width/height [mm] 640/220/550
Weight [kg] 55
