Machine Description
Operating Instructions 878-M PREMIUM - 02.0 - 02/2018 19
4 Machine Description
Fig. 1: Machine Description
(1) - Control panel OP3000
(2) - Tension plate
(3) - Thread lever
(4) - Keypad on the machine arm
(5) - Top roller with needle
(6) - Hook (under throat plate)
(7) - Oil level indicator
(8) - Winder
(9) - Hand wheel
(10) - Electronic hand wheel
(11) - Reel stand
