Operation
Operating Instructions 878-M PREMIUM - 02.0 - 02/2018 47
5.13Sewing
The pedal starts and controls the sewing process.
Fig. 28: Sewing with the peda
Initial position:
• Pedal position 0:
Machine stationary, needles up, top roller down.
To position the material to be sewn:
1. Press the pedal halfway back in pedal position -1:
The sewing feet are lifted.
2. Push the material to be sewn into the initial position.
Sewing:
1. Press the pedal forwards in pedal position +1:
The machine sews.
The sewing speed increases the further forward the pedal
is pressed.
WARNING
Risk of injury from the needle tip when sewing
is started unintentionally!
Take care not to accidentally press the foot pedal
when your fingers are in the needle tip area.
1
2
3
4
(1) - Pedal position +1:
sewing active
(2) - Pedal position 0:
rest position
(3) - Pedal position -1:
moves the sewing feet up
(4) - Pedal position -2:
sewing the end bar tack and
cutting off the thread
