Settings via the software
Operating Instructions 878-M PREMIUM - 02.0 - 02/2018 71
8 Settings via the software
8.1 OP3000 control panel
Fig. 46: Control panel
All settings in the controller for the 878-M PREMIUM are performed
using the OP3000 control panel.
Key Function
0 to 9 Inputting the parameter value (if the field for the parameters
is activated)
Selection of a parameter that is shown on the display
• Press the key under the desired symbol.
The function is selected.
ESC Cancel the function
Exit the menu (changes remain saved)
OK Confirm the settings
Activate the input
P Function is different for each menu
S Function is different for each menu
F Function is different for each menu
Selection to the right
Selection to the left
Back one menu level
Increase the value
Scroll through the list (upwards)
Decrease the value
Scroll through the list (downwards)
A Upper softkey
Assignment is different for each menu
